Trapezoidal velocity profile
A trapezoidal velocity profile plans velocity in constant acceleration, constant velocity, and constant deceleration phases.
Other learning contexts (3)
In context
The area under the velocity–time graph is travel distance. Jerk changes abruptly in the idealized transitions between constant-acceleration phases.
Example
A sufficiently long travel distance includes a maximum-speed phase. For short distances, deceleration must begin before the planned maximum speed is reached.
Key distinction
Distinguish commanded speed from the maximum speed actually reached.
